Technical
resources.
Install documentation, drawings, specs, and tools for door professionals, architects, and designers working with the Moenave system.
The full step-by-step guide, from door supports through final testing. Read it before starting.
Watch a full install by the Moenave crew, step by step alongside the manual.
How to size torsion springs for the trackless system using the spring calculator.
One-page summary for experienced technicians. Print it and bring it to the job.
Mounting, wiring, photo eye connection, and settings for the RGBW light bar.
Update a light from your browser, plus the phone update file and quick setup guide.
Dimensions, tolerances, opening requirements, and hardware details.
AutoCAD drawing for placing the system in construction documents.
Rough opening and framing dimensions. Share with the builder before rough-in.
Door size, opening size, and clearances with the door closed.
Door size, swing arc, and clearances with the door fully open.
Use these for rough-in planning and size verification. Confirm side and ceiling clearance before installation.
Standard sectional doors with a flat interior face. Openings are framed the same as a standard garage door. Full details are in the spec sheet and manual.
Follow along with the installation manual. Pause at any step.
Questions during your install? Call or text 435-229-9141.
Watch on YouTubeWalk through the spring calculation for a trackless install, from door weight to final spring specs.
Run your own numbers in the spring calculator.
Watch on YouTubeLights ship from our shop already flashed, paired, and synced, so updating is optional. The firmware flasher always carries the latest version.
Join the light's Wi-Fi (moenave-light-XXXX), open 192.168.4.1, and find the version in the Firmware section. On v5.31 or newer, you can update from a phone or laptop. Older versions, or no Firmware section, need the USB update.
- Open the firmware flasher in Chrome or Edge on a Mac or Windows computer.
- Plug a USB data cable into the controller board.
- Press Flash light and choose the controller. If it isn't listed, hold MODE while plugging in.
- When it finishes, press reset or unplug and plug back in. Repeat for each light.
For lights on v5.31 or newer.
- Download the phone update file below.
- Join the light's Wi-Fi and open 192.168.4.1.
- In Firmware, choose the file and tap Update all lights. Every light updates and restarts together.
Both updates keep the group, settings, and Wi-Fi password, unless you turn off Keep pairing and settings in the flasher. Lights updated from older 5.x firmware pair again on their own when powered on together. All lights in a garage must run the same version.
Update a light over USB from your browser. Nothing to install. Chrome or Edge on Mac or Windows.
Signed update file for lights on v5.31 or newer. Install it from the light's settings page.
Buttons, animations, phone settings, pairing, updates, and troubleshooting.
Dealers handle sizing, door sourcing, and installation. Find the one nearest your project.
View the Dealer MapQuestions on an opening, a drawing, or a step in the manual. For anything urgent, a call or text is fastest.
